Features



Shapes and substance. When the light shines from the wall.



Basic shapes, indirect illumination, distinctive: all this you can find in the GOCCIA WASH Range. The range comes in two different shapes, a totally rectangular and a Parabolic profile. Both are available with single LED light up or down or double LED light. A version with Opal glass and Linear LED Modules gives a soft and comfortable spread of light and another version with clear glass and a single power LED gives a strong and asymmetric distribution of light. Thanks to the milled ultra-white glass the top is completely flat to avoid water collection. With Lumen Outputs of 1120, 1200 and 1470 respectively each of these new generation LED fittings, both Linear and Power LED give the best in terms of light output and efficiency.

Series Wash

The shapes

A. WASH 22

B. WASH 42

C. WASH 24

D. WASH 52

Opal or clear glass*



E. Opal glass + Linear LED Module

Opal glass to have a soft and comfortable light



F. Clear glass + Power LED

Ultra-white clear glass and adjustable Asymmetric reflectors for a direct, sharp and incisive light.



*Only avilabal on Wash 22 & Wash 24

Simple reflector adjustment

It is quite simple to adjust the reflector: adjustment can be made even if the light is on. Unscrew, lift the reflector, turn 180° and screw.

WASH Rectangular

1. Asymmetric

    Ultra-white clear glass + Power LED – WASH 22



2. Opal glass + Linear LED Module – WASH 22



3. Opal glass + Linear LED Module – WASH 42





WASH Parabolic

4. Asymmetric

    Ultra-white clear glass + Power LED – WASH 24



5. Opal glass + Linear LED Module – WASH 24



6. Opal glass + Linear LED Module – WASH 52

Adjustable Asymmetric reflectors

The Asymmetric reflector can be fixed in two different positions:

G. against the wall to highlight the wall-washer effect or adjusted

H. to illuminate balconies, walkways, corridors etc.

Wash 22 - Opal glass / Asymmetric

  • Milled opal glass

    • 1301   LED  Up and Down

    • 1302   E27  Up and Down

    • 1305   LED  Single light (up or down)

    • 1306   E27  Single light (up or down)

  • Asymmetric Ultra-white clear glass

    • 1308   LED  Up & Down

    • 1309   LED  Single light (up or down)

Wash 24 - Opal glass / Asymmetric

  • Milled opal glass

    • 1321   LED  Up and Down

    • 1322   E27  Up and Down

    • 1324   LED  Single light (up or down)

    • 1325   E27  Single light (up or down)

  • Asymmetric Ultra-white clear glass

    • 1327   LED  Up & Down

    • 1328   LED  Single light (up or down)

Wash 42 - Opal glass

  • Milled opal glass

    • 1311   LED  Up and Down

    • 1312   LED  Single light (up or down)

Wash 52 - Opal glass

  • Milled opal glass

    • 1332   LED  Up and Down

    • 1333   LED  Single light (up or down)
